Super Flux
Part Number |
Chip |
Lens color |
VF(V)at IF=20mA |
Iv(mcd) |
Viewing Angle 2θ 1/2 |
|||||
Material |
Emitted Color |
λD(nm) |
Typ. |
Max. |
at IF=mA |
Min. |
Max. |
|||
Super Flux (5mm Dome) |
UNIT:mm |
|||||||||
 |
 |
|||||||||
GPT923-LO7403/S1 |
AlGaInP |
Red |
625 |
Water Clear. |
2.0 |
2.4 |
20 |
500 |
1500 |
100° |
GPT923-PY7403/S1 |
AlGaInP |
Yellow |
590 |
2.0 |
2.4 |
500 |
1500 |
|||
GPT923-CB5403Q1/S1 |
InGaN |
Blue |
465 |
3.2 |
3.6 |
500 |
1000 |
|||
GPT923-LG5403/S1 |
InGaN |
Green |
525 |
3.2 |
3.6 |
500 |
2000 |
|||
GPT923-WH5403Q1/S1 |
InGaN |
White |
/ |
3.2 |
3.6 |
500 |
2000 |
|||
Super Flux (Arc Top) |
UNIT:mm |
|||||||||
 |
 |
|||||||||
GPT926-LO7403/S1 |
AlGaInP |
Red |
625 |
Water Clear. |
2.0 |
2.4 |
20 |
100 |
800 |
160° |
GPT926-PY7403/S1 |
AlGaInP |
Yellow |
590 |
2.0 |
2.4 |
100 |
800 |
|||
GPT926-CB5403Q1/S1 |
InGaN |
Blue |
465 |
3.2 |
3.6 |
100 |
500 |
|||
GPT926-LG5403/S1 |
InGaN |
Green |
525 |
3.2 |
3.6 |
100 |
1000 |
|||
GPT926-WH5403Q1/S1 |
InGaN |
White |
/ |
3.2 |
3.6 |
100 |
1000 |
|||
Super Flux (3mm Dome) |
UNIT:mm |
|||||||||
 |
 |
|||||||||
GPT928-LO7403/S1 |
AlGaInP |
Red |
625 |
Water Clear. |
2.0 |
2.4 |
20 |
500 |
1500 |
100° |
GPT928-PY7403/S1 |
AlGaInP |
Yellow |
590 |
2.0 |
2.4 |
500 |
1500 |
|||
GPT928-CB5403Q1/S1 |
InGaN |
Blue |
465 |
3.2 |
3.6 |
500 |
1000 |
|||
GPT928-LG5403/S1 |
InGaN |
Green |
525 |
3.2 |
3.6 |
500 |
2000 |
|||
GPT928-WH5403Q1/S1 |
InGaN |
White |
/ |
3.2 |
3.6 |
500 |
2000 |
|||
Super Flux (3mm Oval) |
UNIT:mm |
|||||||||
 |
 |
|||||||||
GPT929-LO7403/S1 |
AlGaInP |
Red |
625 |
Water Clear. |
2.0 |
2.4 |
20 |
500 |
2000 |
70° / 30° |
GPT929-PY7403/S1 |
AlGaInP |
Yellow |
590 |
2.0 |
2.4 |
500 |
2000 |
|||
GPT929-CB5403Q1/S1 |
InGaN |
Blue |
465 |
3.2 |
3.6 |
500 |
1500 |
|||
GPT929-LG5403/S1 |
InGaN |
Green |
525 |
3.2 |
3.6 |
500 |
3000 |
|||
GPT929-WH5403Q1/S1 |
InGaN |
White |
/ |
3.2 |
3.6 |
500 |
3000 |
|||
Super Flux (Flat Top) |
UNIT:mm |
|||||||||
 |
 |
|||||||||
GPT930-LO7403/S1 |
AlGaInP |
Red |
625 |
Water Clear. |
2.0 |
2.4 |
20 |
100 |
800 |
160° |
GPT930-PY7403/S1 |
AlGaInP |
Yellow |
590 |
2.0 |
2.4 |
100 |
800 |
|||
GPT930-CB5403Q1/S1 |
InGaN |
Blue |
465 |
3.2 |
3.6 |
100 |
500 |
|||
GPT930-LG5403/S1 |
InGaN |
Green |
525 |
3.2 |
3.6 |
100 |
1000 |
|||
GPT930-WH5403Q1/S1 |
InGaN |
White |
/ |
3.2 |
3.6 |
100 |
1000 |
|||
Super Flux (3mm Dome) |
UNIT:mm |
|||||||||
 |
 |
|||||||||
GPT934-LO7403/S1 |
AlGaInP |
Red |
625 |
Water Clear. |
2.0 |
2.4 |
20 |
500 |
3000 |
15° |
GPT934-PY7403/S1 |
AlGaInP |
Yellow |
590 |
2.0 |
2.4 |
500 |
3000 |
|||
GPT934-CB5403Q1/S1 |
InGaN |
Blue |
465 |
3.2 |
3.6 |
500 |
2000 |
|||
GPT934-LG5403/S1 |
InGaN |
Green |
525 |
3.2 |
3.6 |
500 |
3000 |
|||
GPT934-WH5403Q1/S1 |
InGaN |
White |
/ |
3.2 |
3.6 |
500 |
3000 |
|||
