型号 Model
|
GPT-UNISTWF-0008
|
|
输入电压: Input Voltage
|
100-240V AC
|
|
电源频率: Frequency
|
50~60Hz
|
|
功率因素 (PF)
|
＞0.95
|
|
总谐波失真( Thd)
|
＜20%
|
|
电源效率 Power Efficiency
|
＞90%
|
|
光源工作电压: Working Voltage
|
24V DC
|
|
LED数量: LED Qty
|
56×1W
|
|
灯具系统功耗: Power Consumption
|
72W
|
|
LED发光效率: Luminous Efficiency
|
≥100 lm/W
|
|
LED初始光通量: Initial luminous
|
5400 lm (Tj=25℃)
|
|
LED正常光通量: Normal luminous
|
5100 lm(Tj=60℃,Ta=25℃)
|
|
灯具出光效率 (%): Light Extraction Efficiency
|
＞90%
|
|
照度(E)及有效照射范围: Lux ad effective illuminated area
|
(高度=6m) 28 Lx 21×9.5m
(高度=8m) 16 Lx 28×13m
|
|
相关色温: CCT
|
暖白 Warm White:3,000~4,000K; 正白Day Light:4,000~4,500K; 冷白 Cool White:5,500~6,500K
|
|
显色指数(CRI):
|
Ra＞75
|
|
光束角: Beam Angle
|
130°×80°
|
|
结温(Tj):
|
＜65 ℃ ± 1 0% ( Ta= 25 ℃)
|
|
系统热阻 (Rja):
|
0.45℃ / W
|
|
工作温度: Working Temp
|
- 20 ℃ ~ 40 ℃
|
|
工作湿度: Working Humidity
|
10 % ~ 90 % RH
|
|
贮藏温度: Storage Temp
|
-20 ℃ ~ 45 ℃
|
|
使用寿命 Lifespan
|
50,000 Hrs
|
|
灯体材质: Housing Material
|
铝合金+钢化玻璃 Aluminium + Tempered Glass
|
|
防护等级: IP Standard
|
IP65
|
|
灯具尺寸: Dimension
|
552× 398 ×132 mm
|
